AS-606T
A high capacity NAS server designed for small to medium sized businesses
The AS-606T offers a high capacity data storage solution. Meticulously crafted data protection and backup features provide comprehensive protection for your company's digital assets.
  • Windows + Mac + Linux cross-platform file sharing
  • Outfitted with SuperSpeed USB 3.0 and SATA III ports
  • Support for Windows Active Directory
  • Military grade AES 256-bit encryption for individual shared folders
  • Support for RAID 0, 1, 5, 6, 10 and hard drive hot swapping
  • Your complete backup solution
  • Comparision Table
    Why ASUSTOR?
    Your Data is Safe with Us
    Embrace the Cloud, Enjoy Peace of Mind
    iSCSI and Virtualization
    Unleash Unlimited Potential
    Why ASUSTOR?
    In the wake of technological advancements, information and data are becoming digitized in ever-increasing amounts, creating so-called "digital assets". Following increasing demand and the above-mentioned technological advancements, digital assets are continually growing at an exceptionally rapid rate. Ensuring the security of these digital assets, simplifying their management, and lowering the TCO (Total Cost of Ownership) are becoming important issues in the IT field for both individuals and businesses alike.

    ASUSTOR NAS devices are able to provide optimal data protection through RAID technology. A diverse array of automatic backup solutions are also supported, guaranteeing the security of your data. Seamless cross-platform file sharing allows you to easily connect to your NAS device no matter if you are using Windows, Mac OS, or Unix-like operating systems. When paired with mobile applications (iOS and Android), ASUSTOR's exclusive Cloud Connect™ technology lets you access the data from your NAS device from almost anywhere on the planet.

    Additionally, our NAS devices can also be used with virtual environments such as VMware, Citrix and Hyper-V. They also support the use of NFS and iSCSI in the creation of shared storage for virtual environments, making them an ideal alternative to SAN. ASUSTOR NAS devices are able to offer both flexible and cost-effective storage solutions, making them a must-have for your virtualization infrastructure.

    Your Data is Safe with Us
    You no longer need to worry about accidentally losing your vital documents. ASUSTOR NAS devices provide you with a complete host of data protection and backup solutions to look after your most important information, creating a stress free and liberating user experience.

    Optimal data security solutions – abundant data protection and backup features

    Using backup utilities such as Backup Plan and Apple Time Machine you can easily backup data from a Windows PC or Mac directly onto an ASUSTOR NAS device. ASUSTOR NAS devices also offer a variety of different RAID configurations, allowing you to select the most appropriate configuration for your security needs.

    Moreover, our NAS devices also support a multitude of two-way sync and backup options. Besides backing up your data onto a NAS device, you can also further back up the data from a NAS device onto other devices. ASUSTOR NAS devices support backup via the cloud, external hard drive, Rsync and FTP. In the unfortunate event of a disaster, you will be able to recover and restore your data with the utmost speed, thereby helping you to avoid the damage that can be caused by lost data.
    Embrace the Cloud, Enjoy Peace of Mind
    ASUSTOR NAS devices allow you to enjoy the conveniences of cloud computing, while simultaneously providing you with data security of the highest standard.

    All our devices come pre-installed with ADM Defender, which protects your data against all malicious attacks. Secure multitenancy and SSL encryption allow all users to access their data in a protected and stress free environment. As well, our NAS devices also support military grade AES 256-bit encryption for each individual shared folder, giving you the type of security and privacy that you require for your most confidential data. This means that, should you lose your NAS device, you still needn't worry about your sensitive data falling into the wrong hands.

    In addition to providing security for your data, ASUSTOR also caters to your other security interests. Our pre-installed Surveillance Center lets you collectively manage an array of IP cameras. Through the power of the Internet, you can keep an eye on all of your valued interests. In the event of any disruptions, Surveillance Center will notify you at once.
    iSCSI and Virtualization
    ASUSTOR recognizes that stable and efficient shared storage is a must for your virtual environment. The supported use of iSCSI and NFS allows you to seamlessly integrate with any existing IT environments. Additionally, all ASUSTOR NAS devices are verified as VMware, Citrix and Hyper-V ready, providing you with a flexible and cost-efficient virtual storage solution.

    The iSCSI features supported by ASUSTOR NAS devices include:
    - LUN Mapping
    - LUN Masking
    - ISO File Mounting
    - MPIO & MCS Support
    - Persistent (SCSI-3) Reservations
    Unleash Unlimited Potential
    The applications that come pre-installed with each ASUSTOR NAS device are just the beginning. At your convenience, you can browse through and download any applications that peak your interest from App Central. App Central allows you to explore the unlimited potential of ASUSTOR NAS devices while creating a personalized NAS device for yourself.

    Whether your interests lie in business, website construction or even digital home entertainment, App Central provides you with the boundless variety of applications that you require to satisfy your digital lifestyle needs.

    Windows Read/Write (5GB file)


    Series Read Write
    AS-6 111.18 108.66
    AS-3  110.38 81.74
    AS-2TE 101.36 70.32
    AS-2T 98.68 65.88

    iSCSI Read/Write (5GB file)

    Series Read Write
    AS-6 99.24 97.88
    AS-3  86.76 86.52
    AS-2TE 83.52 83.61
    AS-2T 83.18 79.14

    Test Enviroment

    Client PC
    CPUIntel Core i5-2320 3.00GHz
    Memory2GB
    OSWindows 7 x64, Ubuntu Server 12.10 x64
    HDDToshiba MQ01ABD032 *2 [Raid0]
    Network1Gbps Ethernet, MTU 1500
    SwitchDLink DSG-1210-16
    NAS
    OSADM 2.0.2.R899
    HDDWD10EFR
    Network1Gbps Ethernet, MTU 1500
    SwitchDLink DSG-1210-16

    • Tested models: AS-604T/AS-304T/AS-204TE/AS-204T
      Tested RAID level: RAID 5

    • Performance figures are achieved in the ASUSTOR lab using state of the art client computers under optimized network settings, and could vary in different environments. Ordinary desktop or notebook computers may be unable to reproduce these figures.

    Hardware & Packaging

    Hardware Specifications

    • CPU: Intel® Atom™ 2.13 GHz Dual-Core Processor
    • Memory: 1GB SO-DIMM DDR3 (Expandable. Max. 3GB) Installation Guide
    • HDD: 2.5" / 3.5" SATA II/ III or SSD x 6¹ Compatibility
    • Expansion: USB 3.0 x 2, USB 2.0 x 4, eSATA x 2
    • Network: Gigabit Ethernet x 2
    • LCD Panel
    • Output: HDMI 1.3a x1
    • System Fan: 120mm x 1
    • Input Power Voltage: 100V to 240V AC
    • Certification: FCC, CE, VCCI, BSMI, C-TICK

    Operation

    • Power Consumption: 40.3W (Operation); 30.2W (Disk Hibernation); 1.4W (Sleep Mode)²
    • Noise Level: 22.8 dB(A)
    • Operation Temperature: 5°C~35°C (40°F~95°F)
    • Humidity: 5% to 95% RH

    ASUSTOR Hightlight

    • System Migration
    • Cloud Connect
    • Dr.ASUSTOR
    • 2-way Backup
    • Task Monitor

    Eco-Friendly Design

    • System Sleep Mode (S3)
    • Auto-Standby for Both Internal and External Disks
    • Auto Fan Control
    • LED Night Mode
    • Power Schedule: On, Off, Restart, and Sleep

    Size and Weight

    • Size: 185.5(H) x 233(W) x 230(D) mm
    • Weight: 4.3 kg / 9.48 lb

    Software & Features

    Operating System

    • ADM 1.0 Onwards
    • Built-in App Central for Various Apps

    Supported OS

    • Windows XP, Vista, 7, 8, Server 2003, Server 2008, Server 2012
    • Mac OS X 10.6 Onwards
    • UNIX, Linux, and BSD

    Supported Languages

    • Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Español

    Supported Browsers

    • Internet Explorer 9 Onwards
    • FireFox
    • Chrome
    • Safari

    Network Protocols

    • CIFS/SMB, AFP, NFS, FTP, WebDAV, Rsync, SSH, SFTP, iSCSI, HTTP, HTTPS

    File System

    • Internal Disk: EXT4
    • External Disk: FAT32, NTFS, EXT3, EXT4, HFS+

    Storage Management

    • Support Multiple Volumes with Spare Disks
    • Volume Type: Single disk, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
    • Support for Online RAID Level Migration
    • Support for Online RAID Capacity Expansion

    MyArchive

    • Insert Hard Disk & Immediately Access Files
    • Transfer or Exchange Terabytes of Data via the Internal Hot-Swap SATA Interface
    • Up to 2 Bays Reserved for MyArchive Docking Purposes

    iSCSI

    • Maximum Targets: 256
    • Maximum LUNs: 256
    • Target Masking
    • LUN Mapping
    • ISO File Mounting
    • Supports MCS
    • Persistent (SCSI-3) Reservations

    Disk Management

    • Scheduled Bad Block Scans
    • Scheduled S.M.A.R.T Scans

    Network

    • TCP/IP (IPv4 & IPv6)
    • Link Aggregation: Supports 802.3ad and Six Other Modes for Load Balancing and/or Network Failover
    • Jumbo Frame (MTU)
    • VLAN
    • Cloud Connect
    • Wireless Network³
    • DDNS and EZ-RouterCompatibility
    • Supports Wake-on-LAN (WOL)

    Backup Solutions

    • Rsync (Remote Sync) Backup
    • Cloud Backup
    • FTP Backup
    • External Backup
    • One Touch Backup

    System Administration

    • Log Type: System Log, Connection Log, File Access Log
    • Real-time Online User Monitor
    • Real-time System Monitor
    • Network Recycle Bin
    • User Quota
    • Virtual Drive (ISO Mounting, Maximum 16)
    • UPS SupportCompatibility

    Access Control

    • Maximum Number of Users: 4096
    • Maximum Number of Groups: 512
    • Maximum Number of Shared Folders: 512
    • Maximum Number of Concurrent Connections: 512
    • Supports Windows Active Directory

    Security

    • AES 256-Bit Folder Encryption
    • Firewall: Prevent Unauthorized Access
    • Network Defender: Prevent Network Attacks
    • Alert Notifications: E-mail, SMS
    • Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH

    External DevicesCompatibility

    • Supports USB/eSATA3 External Storage Devices
    • USB Wi-Fi Dongle Support
    • Bluetooth Dongle/Speaker Support
    • USB Printer Support
    • USB DAC/IR Receiver/Keyboard/Mouse Support

    Featured Apps

    Antivirus

    • Scheduled Scans
    • Automatic Virus Definition Updates
    • Quarantine Infected Files

    ASUSTOR Portal⁶

    • Supports 2 Different Multimedia Players: XBMC & Boxee *
    • Supports Output for 4 Channels of Megapixel IP Camera Video Feeds
    • Chrome Web Browser and YouTube Integration
    • Downloads from Chrome Automatically Saved to the NAS
    • Power Control Settings: Power on, Sleep, Restart and Wake via Remote
    • Customizable ASUSTOR Portal Desktop Wallpaper
    • Add Shortcuts to Favorite Websites
    • Increased TV Compatibility via Overscan and Resolution Settings

    Boxee / XBMC⁷

    • Play All Media Content Stored on NAS
    • Video Output via HDMI
    • TV Shows, Movies, Apps and More
    • ASUSTOR Customized Features
    • AiRemote Mobile App
    • Supports SBS 3D Playback (Side By Side)

    Download Center

    • Supports BT(Torrent & Magnet Link), HTTP and FTP Downloads
    • Torrent Search
    • Choose Files Before a BT Task Starts
    • Customizable Download Schedule
    • Bandwidth Control
    • RSS Subscription and Automatic Downloading (Broadcatching)
    • ASUSTOR Download Assistant for Windows & Mac
    • AiDownload for iOS & Android
    • AiDownload for iOS & Android with Push Notification
    • Smart Download Function

    File Explorer

    • Web-based File Management
    • ISO File Mounting
    • Share Links
    • Task Monitor
    • Browse Files on Local PC
    • Thumbnail Previews

    FTP Explorer

    • Directory Structure View with Drag & Drop Transfers
    • Task Monitor
    • Stopping of Transmission Task & Resumption of Connection
    • Encrypted Connections: Explicit over TLS, Implicit over TLS
    • FTP Site Manager
    • Bandwidth Control
    • Maximum Simultaneous Transfer Control

    iTunes Server

    • For iTunes on Mac & Windows
    • Supports AirPlay
    • Supports iOS Remote Pairing
    • Supported Audio Formats: AIF⁵, M4A (AAC & Apple Loseless), M4P, M4R, MP3, WAV⁵
    • Supported Video Formats: M4V, MOV, MP4
    • Supported Playlist Formats: M3U, WPL

    Surveillance CenterCompatibility

    • Live Monitoring (4 Free Channels)
    • Multiple Channel Playback with Audio
    • Supported Browsers: Internet Explorer, Chrome, FireFox (Windows only)
    • Event Notification
    • Supports Local Output of 4 Video Feed Channels
    • Recording via Schedule and Event Detection
    • Add Additional IP Camera Channels via Purchasable Licenses

    SoundsGood

    • Import Personal/Public Music Collection
    • Personal/Public Music Collection Permission Control
    • Playlist Editor
    • ID3 Tag Editor
    • Local Speaker Support: HDMI, USB
    • Supported Audio Formats for Browser: MP3, WAV, Ogg
    • Supported Audio Formats for Transcoding Through Browser: AIFF, Flac
    • Supported Audio Formats for Local Speaker: MP3, WAV, Ogg, AIFF, Flac
    • ASUS DAC Support

    Takeasy

    • Download from YouTube, Vimeo, YouKu, Tudou and More
    • Selectable the Video Type and Quality
    • Automatic Downloads with YouTube Subscriptions
    • Preview Downloads in Progress
    • Online Playback

    UPnP Media Server

    • Supports PS3 and other Digital Media Player Capable Devices
    • Supports On-The-Fly Transcoding for Most RAW Images and Audio(OGG, FLAC)
    • Supported Image Formats: BMP, GIF, ICO, JPG, PNG, PSD, TIF, RAW Image⁴ (3FR, ARW, CR2, CRW, DCR, DNG, ERF, KDC, MEF, MOS, MRW, NEF, NRW, ORF, PEF, RAF, RAW, RW2, SR2, X3F)
    • Supported Audio Formats: 3GP, AAC, AC3, AIFC, AIFF, AMR, APE, AU, AWB, FLAC1, M4A, M4R, MP2, MP3, OGG Vorbis1, PCM, WAV, WMA
    • Supported Video Formats: 3GP, 3G2, ASF, AVI, DAT, FLV, ISO, M2T, M2V, M2TS, M4V, MKV, MPv4, MPEG1, MPEG2, MPEG4, MTS, MOV, QT, SWF, TP, TRP, TS, VOB, WMV, RMVB, VDR, MPE

    VPN Client

    • Supported VPN Protocols: PPTP, OpenVPN
    • Transmission Package Monitor
    • PPTP Authentication: PAP, CHAP, MS CHAP, MS CHAP2
    • PPTP Encryption: No MPPE, MPPE (40, 128 bit), Maximum MPPE (128 bit)
    • OpenVPN Port Control
    • OpenVPN Link Compression

    VPN Server

    • Supports PPTP and OpenVPN Protocols
    • View Current Connections & Ability to Disconnect Suspicious Connections
    • Comprehensive Connection Log
    Note:
    ¹ Hard disks not included.
    ² Test HDD: WD Red 3 TB HDD
    ³ USB Wi-Fi dongle not included.
    ⁴ You must first enable real time transcoding for these files in order to play them.
    ⁵ Metadata (e.g. title) may not be able to displayed in iTunes.
    ⁶ ASUSTOR recommends that ASUSTOR Portal be used with a TV with a resolution of 720p or higher or a monitor supporting audio output.
    ⁷ Currently, Boxee is only available on the 6 series.

    Package Contents

    • Package Weight: 5.4 kg/11.90lbs
    • Package Size: 324(H) x 310(W) x 300(D) mm

    Package Contents

    AS-606T Unit x1 Installation CD x1 AC Power Cord x1
    RJ-45 LAN Cable(Cat 5e) x2 Flat Head Screw (for 3.5" HDD) x24 Flat Head Screw (for 2.5" HDD) x24
